Datasheet(pdf 115.60 KB) BBI5731/1- Inclinometer, ±15°, bubble type with exp chamber
Features
- Solid machined acetal housing
- Range of use ±15°
- Precision glass vial
- Yellow/Green liquid
- Waterproof finish
- Expansion Chamber
Applications
Product Specification
| Length | 350 | mm |
| Range | ±15° | – |
| Resolution | 0.5° | – |
| Accuracy | 10% | – |
| Height | 100 | mm |
| Width | 16 | mm |
| Measuring Type | Bubble | – |
| Case Material | Acetal | – |
| Vial Material | Glass | – |
| Mounting Method | Screw fixing (vertical surface) | – |
| Bubble Size | 10 | mm |
| Expansion Chamber | Yes | – |
| Light | none | – |
